The Cube-eye S130D is a high-resolution ToF 3D camera built for accurate depth sensing up to 6 meters. Powered by a Samsung ISOCELL ToF image sensor, it delivers real-time depth information at up to 30fps. Its extended range makes it suitable for autonomous mobile robots, smart logistics, and industrial automation where reliable spatial awareness and wider-area coverage are essential.
Key Features for Reliable Depth Sensing
- Up to 6m measurement range: Covers a wider working area from a single camera installation point.
- Real-time depth data: Supports 7.5, 15, and 30fps for different application requirements.
- Reduced host processing: An integrated ASIC companion chip helps lower the processing workload on the host system.
- Accurate measurements: Provides 10mm accuracy up to 1m and approximately 1% accuracy by distance.
- Multiple data outputs: Depth, amplitude, and point-cloud data support a range of 3D vision applications.
- Flexible software support: Compatible with Linux, Windows, Android, ROS1, and ROS2.
Practical Performance for Automation Systems
The S130D combines long-distance sensing, true VGA resolution, and a 60° × 45° field of view in a compact design. With MIPI CSI-2 and USB 3.0 interfaces, it can be integrated into different system architectures. Its low average power consumption and Class 1 eye-safety certification further support its use in embedded robotics and industrial vision applications.
Specifications That Support Easy Integration
- True VGA resolution: 640 × 480 provides detailed 3D depth data for sensing tasks.
- Wide sensing capability: Measures from 0.2 to 6m, supporting long-range spatial awareness.
- 940nm VCSEL: Uses a 2W VCSEL light source for ToF depth measurement.
- Compact and lightweight: The MIPI version weighs 11.8g, while the USB version weighs 20.2g.
- Power efficient: Average power consumption is approximately 1.5W.
- Multiple certifications: Meets KC, CE, RoHS, and FCC requirements.
Why Choose the Cube-eye S130D for 3D Sensing?
With its combination of 6m range, precise depth measurement, real-time performance, and flexible connectivity, the Cube-eye S130D provides a practical solution for modern 3D vision systems. It can help machines gain better awareness of their surroundings across robotics, logistics, and industrial automation applications.
